Other bearings - Peer bearing units
Browse to product table
Interested in buying products?
Want to know more about the prices or order directly? This is possible when you are affiliated with a dealer in your area. Do you want to sell products via Kramp as a dealer? Then sign up!
- Tailored advice from our specialists
- More than 500.000 products
- Up-to-date information on current stock and delivery times
| Long description | PEER bearings are high-precision components crucial for the smooth operation of rotating shafts, wheels, pulleys, etc. PEER bearings ensure a long service life in a wide variety of applications and industries. This product line includes deep groove ball bearings, tapered roller bearings, bearing blocks, agricultural bearings,... Show more |
|---|
Interested in buying products?
Want to know more about the prices or order directly? This is possible when you are affiliated with a dealer in your area. Do you want to sell products via Kramp as a dealer? Then sign up!
- Tailored advice from our specialists
- More than 500.000 products
- Up-to-date information on current stock and delivery times
Product | Unit | Bearing inside diameter d | Outside diameter D | Bearing inner ring width Bi | Housing width Be | Total length | Number of mounting holes | Weight | Bearing material | Basic radial load static | Basic radial load dynamic | Mounting holes width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Each | 16,256 mm | 40 mm | 18 mm | |||||||||
| Each | 16,053 mm | 45,2 mm | 18,67 mm | 15,5 mm | ||||||||
| Each | 22,25 mm | 52 mm | 25,4 mm | 15 mm | ||||||||
| Each | 25,43 mm | 62 mm | 24 mm | 16 mm | ||||||||
| Each | 28,6 mm | 72 mm | 25 mm | 17 mm | ||||||||
| Each | 16,25 mm | 40 mm | 44,12 mm | 39,12 mm | ||||||||
| Each | 31,75 mm | 41,4 mm | 41,4 mm | 127 mm | 4 | |||||||
| Each | 100 mm | 42 mm | 4 | 1,71 kg | Steel | 7800 N | 14000 N | |||||
| Each | 16,25 mm | 47 mm | 44,12 mm | 0,27 kg | ||||||||
| Each | 16,256 mm | 40 mm | 18,29 mm | 0,84 kg | Steel | 4790 N | 9750 N | |||||
| Each | 16,256 mm | 40 mm | 18,28 mm | 0,083 kg | ||||||||
| Each | 16,256 mm | 40 mm | 18,29 mm | 0,84 kg | Steel | 8900 N | 14400 N | |||||
| Each | 13,081 mm | 40 mm | 18,29 mm | 0,1 kg | Steel | 8900 N | 14400 N | |||||
| Each | 16,053 mm | 45,2 mm | 18,67 mm | 0,125 kg | Steel | 12200 N | 19300 N | |||||
| Each | 16,053 mm | 45,2 mm | 18,67 mm | 0,13 kg | ||||||||
| Each | 16,053 mm | 45,2 mm | 18,67 mm | 0,127 kg | Steel | 12400 N | 19600 N | |||||
| Each | 75 mm | 31,27 mm | 28 mm | 0,51 kg | Steel | 12400 N | 19600 N | |||||
| Each | 22,25 mm | 52 mm | 25,4 mm | 0,176 kg | ||||||||
| Each | 16,129 mm | 53 mm | 19,43 mm | 0,206 kg | ||||||||
| Each | 19,202 mm | 52 mm | 21,1 mm | 0,173 kg | ||||||||
| Each | 22,7 mm | 62 mm | 22 mm | 0,29 kg | ||||||||
| Each | 25,425 mm | 62 mm | 24 mm | 0,259 kg | ||||||||
| Each | 31,775 mm | 72 mm | 25 mm | 0,36 kg | Steel | 15300 N | 25700 N | |||||
| Each | 16,256 mm | 40 mm | 44,12 mm | 0,21 kg | Steel | 8800 N | 14200 N | |||||
| Each | 16,256 mm | 40 mm | 44,12 mm | 0,22 kg | ||||||||
| Each | 16,1 mm | 47 mm | 24,6 mm | 0,21 kg | Steel | 10700 N | 15540 N | |||||
| Each | 35 mm | 62 mm | 14 mm | 0,16 kg | Steel | 10400 N | 16200 N | |||||
| Each | 25 mm | 52 mm | 15 mm | 0,13 kg | Steel | 7880 N | 14020 N | |||||
| Each | 30 mm | 62 mm | 16 mm | 0,2 kg | Steel | 11310 N | 19460 N | |||||
| Each | 30 mm | 62 mm | 16 mm | 0,2064 kg | Steel | 11310 N | 19460 N | |||||
| Each | 35 mm | 72 mm | 17 mm | 0,29 kg | Steel | 15300 N | 25670 N | |||||
| Each | 50 mm | 110 mm | 27 mm | 1,07 kg | Steel | 37900 N | 61900 N | |||||
| Each | 127 mm | 49,6 mm | 4 | 1,707 kg | Steel | 20460 N | 32710 N | |||||
| Each | 127 mm | 42,79 mm | 4 | 1,676 kg | Steel | 20460 N | 32710 N | |||||
| Each | 139,7 mm | 55,48 mm | 4 | 2,54 kg | ||||||||
| Each | 25 mm | 52 mm | 21,5 mm | 31 mm | 0,2 kg | Steel | 7880 N | 14000 N | ||||
| Each | 30 mm | 62 mm | 23,8 mm | 35,7 mm | 0,289 kg | Steel | 11300 N | 19500 N | 36 mm | |||
| Each | 30 mm | 62 mm | 23,8 mm | 35,7 mm | 0,305 kg | Steel | 11300 N | 19500 N | ||||
| Each | 35 mm | 72 mm | 25,4 mm | 38,9 mm | 0,5 kg | Steel | 15300 N | 25700 N | ||||
| Each | 127 mm | 42,78 mm | 4 | 1,64 kg | ||||||||
| Each | 38,989 mm | 85 mm | 30,16 mm | 0,673 kg | ||||||||
| Each | 29,413 mm | 90 mm | 30,16 mm | 0,865 kg | ||||||||
| Each | 55,575 mm | 100 mm | 33,33 mm | 0,93 kg | ||||||||
| Each | 45,339 mm | 100 mm | 44,45 mm | 1,33 kg | ||||||||
| Each | 55,575 mm | 100 mm | 33,34 mm | 0,86 kg | ||||||||
| Each | 112,725 mm | 116,6 mm | 53,97 mm | 1,679 kg | ||||||||
| Each | 55,575 mm | 100 mm | 33,34 mm | 0,835 kg | Steel | 29220 N | 43380 N | |||||
| Each | 38,887 mm | 100 mm | 33,32 mm | 1,25 kg | ||||||||
| Each | 68,278 mm | 125 mm | 68,26 mm | 2,3 kg | ||||||||
| Each | 70 mm | 125 mm | 39,69 mm | 1,57 kg | ||||||||
| Each | 30 mm | 62 mm | 36,4 mm | 48,3 mm | 0,34 kg | Steel | 11300 N | 19500 N | ||||
| Each | 30 mm | 62 mm | 36,4 mm | 48,3 mm | 0,4 kg | Steel | 11300 N | 19500 N | ||||
| Each | 40 mm | 80 mm | 42,8 mm | 56,3 mm | 0,88 kg | Steel | 20000 N | 32600 N | ||||
| Each | 40 mm | 80 mm | 42,8 mm | 56,3 mm | 0,759 kg | Steel | 20000 N | 32600 N | ||||
| Each | 16 mm | 72 mm | 23 mm | 6 | 0,35 kg | Steel | ||||||
| Each | 18 mm | 78 mm | 23 mm | 6 | 0,51 kg | Steel | ||||||
| Each | 100 mm | 73 mm | 100 mm | 5 | 0,965 kg | Steel | 12600 N | 19300 N | ||||
| Each | 100 mm | 73 mm | 100 mm | 5 | 1,06 kg | Steel | 12600 N | 19300 N | ||||
| Each | 140 mm | 98,5 mm | 140 mm | 5 | 2,95 kg | Steel | ||||||
| Each | 16 mm | 72 mm | 23 mm | 6 | 0,45 kg | |||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
